Our factory, with 50000 square meters and advanced equipemts,we are a trustworthy enterprise and we own a high-class cooperation team.
"Quality First, Customer Satisfaction" is the aim of our factory."Honest to work and live" is the service philosophy of our factory.
We will offer customers machines with good quality,reasonable price and permanent service. We will pay back the supporting and love of new and good clients.
Model Parameter | DL-65 | DL-70 | DL-80 | DL-90 | DL-120 | DL-150 |
Pay-off mode | Dual spool | Dual spool | Dual spool | Dual spool | Dual spool | Dual spool |
Pay-off bobbin | PN500-630 | PN500-630 | PN500-630 | PN630-800/1200 | PN1600-2000 | PN2000-2500 |
Screw dia.(mm) | Φ65 | Φ70 | Φ80 | Φ90 | Φ120 | Φ150 |
L/D | 26:1 | 26:1 | 26:1 | 26:1 | 26:1 | 26:1 |
Extrusion output(kg/h) | 120 | 140 | 200 | 300 | 400 | 500 |
Mainframe power(HP) | 25 | 30 | 40 | 60 | 70 | 100 |
Suitable wire dia.(mm) | Φ1.0-10 | Φ1.2-12 | Φ2.0-20 | Φ3.0-25 | Below Φ50 | Φ6.0-120 |
Cooling trough | Single layer U-form | Single layer U-form | Single layer U-form | Single layer U-form | Single layer U-form | Single layer U-form |
Capstan power(HP) | 5 | 5 | 7.5 | 7.5 | 10 | 10 |
Line speed(m/min) | Max. 400 | Max. 400 | Max. 300 | Max. 200 | Max. 100 | Max. 100 |
Take-up set | Dual spool | Dual spool | Dual spool/big spool | Dual spool/big spool | Big spool | Big spool |
Mobile,Wechat,whatsapp:+8618863443017
Laiwu Guahua Rubber &Plastic Electric Machinery Factory
https://lwguanhua.en.alibaba.com/
Add:7 Wangfushan, Laiwu City,Shandong ,China
Routes: Fly to Jinan Airport, or Taian Railway Station,we will pick you up.
| コンタクトパーソン : | Michael |
|---|
