Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc. Beverage bottle, cosmetic bottle, medicine bottle, jar etc.
High Speed Film Blowing Part | ||
Model | 600 | |
Dia. of Screw | Φ45mm | |
Ratio of Screw | 30:1 | |
Speed of Screw | 10-150rmp | |
Max. Output | 45-55Kgs/h | |
Power of Main Motor | 15kw | |
Die Model | Φ50mm | |
Thickness of Film | 0.008-0.05mm | |
Max Folding Width of Film | 200-400mm | |
Machine Weight | 2t | |
Machine Dimension | 3500*2200*4600mm | |
It is fit to puff high density and low density polyethylene industry film, farm-oriented mulch film. The cylinder and the screw stems of the extruder are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after nitrogen treatment and precision finishing. It is double rolling and account the meter automatically.
Super High Speed T-shirt Bag Making Part | ||
Model | 450 | |
Max Bag Width | 400mm | |
Max Bag Length | 700mm | |
Thickness of material | 0.008-0.05mm | |
Machine Speed | 280-350PCS*2/min | |
Power of Main Motor | 1.8kw | |
Machine weight | 2600kg | |
Machine Dimension | 8000mm*1900mm*1800mm | |
Folding | 750/600mm | |
Name: Die head
inside spiral, center feed
45C steel die runner hard chromium plating
fixed die or rotary die head
Name: Screw
Original: Zhoushan, China
With automatic suction function
it brings great convenience
1 -- 2 colors pint can be available choose
Flexographic or gravure printing type can be available choose
Ruian Songsheng Machinery Co., Ltd is located in China's plastic machinery production base- Ruian city. Company specialized in manufacturing film blowing machine, plastic bag machines and other equiped machines in one line for more than 10 years. We strive for quality and innovation in machine. We export the machines to worldwide as Southeast Asia, the Middle East, South Asia, Russian, North Asia, North America, Eastern Europe, Africa etc. Most welcome from all country to visit our company.
Please click this company picture back to the homepage if need.
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Pick up customer from air-port and stations.
*Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Q: Are you factory or trading company?
we are the manufacturer/factory for film blowing machine, plastic bag machine & printing machine etc.
Q: How does your factory do quality control?
We have profession engineers' team to prove and ensure machine quality.
Q: Machine warranty?
one year since machines arrived your port.
Q: What's your delivery time?
Normally, it need 15 to 20 working days since get the deposit.
Q: How do you keep the after-sales service?
We do business based on faith, we insist on " quality is the first and most important" . We will carefully check the material, produce, test and adjust machines again and again. If have any doubts, please contact us online or by calling, we will reply ASAP.
Q: Where's your company located? how can we visit?
Our company located in Jingye Road, Ruian Economic Development Zone. You can by air to Wenzhou airport or by bullet train to Ruian Station. We welcome all friends from the world for future cooperation.
