Sheet BOGDA PET High Gloss Film Roll Sheet Extrusion Production Line

1.0 Sets
MOQ
Sheet BOGDA PET High Gloss Film Roll Sheet Extrusion Production Line
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
Application: Sheet, Film
Plastic Processed: PET
Condition: New
Screw Design: Single-screw
Screw Material: 38CrMoALA
Screw diameter (mm): 120
Screw L/D Ratio: 33:1
Screw Speed (rpm): 34.7 rpm
Showroom Location: Egypt, Turkey, Italy, Pakistan, India, Russia, Thailand, South Korea, Malaysia
Voltage: 380V/220V/440V
Dimension(L*W*H): 5000*3000*1400mm
Power (kW): 110
Weight: 13000 KG
Warranty: 1 Year
Key Selling Points: Competitive Price, full automatic
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Bevera
Marketing Type: New Product
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Warranty of core components: 1 Year
Core Components: Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox, Screw
Product name: BOGDA PET High Gloss Film Roll Sheet Extrusion Production Line
Normal operating temperature: 130-150℃
Instantaneous service temperature: 180-200℃
Sheet Color: Transparent/white/black/cream/white...
Inverter: ABB Inverter
Contactor: Siemens Contactor
Temperature control: Omron Brand
Control: SIEMENS PLC+Touch Screen
PET Sheet Type: Sheet/Roll
Machine type: Plastic PET sheet extruder
基本情報
お支払配送条件
Packaging Details: Film and plywood case packaging for BOGDA PET High Gloss Film Roll Sheet Extrusion Production Line
Supply Ability: 400 Set/Sets per Year PET sheet production line
製品の説明
Production Application
PETG is a transparent and amorphous copolyester. PETG sheet has outstanding toughness and high impact strength, the impact strength of which is 3-10 times that of modified polyacrylate, and has a wide processing range, high mechanical strength and excellent flexibility. Compared with PVC, PETG sheet has high transparency, good gloss, easy printing and environmental protection advantages.

Using conventional methods of molding, can be prepared 1 ~ 25.4 mm thick transparent material, outstanding toughness and high impact strength, the impact strength is modified polyacrylic ester 3 ~ 10 times, excellent formability, cold bending is not white, no crack, easy to printing and decorate, widely used in indoor and outdoor signs, store content wearing, vending machine panel, furniture, construction and mechanical damper, etc.

PET stereoscopic optical grating sheet is widely used in three-dimensional anti-counterfeiting outer packaging of cosmetics, pharmaceuticals, tobacco and wine packaging and general commodities as well as stationery, pendant, advertising, posters, all kinds of cards, hanging cards and other fields.

CPET sheet is a modified PET with high temperature resistance, usually used in microwave oven baking tray, etc.

On the surface of the wood coated with a layer of PET high-gloss film, making the surface of the wood smooth and bright, not easy to wear.
Product Description
BOGDA PET High Gloss Film Roll Sheet Extrusion Production Line
PET sheet material single screw exhaust production line only needs to PET crystallization, do not need to dry. Its advantages: low energy consumption, simple process, convenient equipment maintenance.
PET sheet extruder
PET sheet extrusion mould
PET sheet rollers
Product Paramenters
Model
Multi layer
Single layer
Highly-efficient
Extrusion specification
SJ120/65-1000
SJ120-1000
SJ150-1500
Product Thickness (mm)
0.20-1.5
0.2-1.5
0.2-1.5
Motor Power (kw)
110/45
110
160
Max. Capacity (kg/h)
500
450
800
Related Products
Shipping & Packaging
Our Service
BOGDA Service For Each of BOGDA Plastic Extrusion Machinery
Pre-sale services:
Based on the clients' request and budget, we will offer equipment pictures, working site videos, plant processing diagram, assemble drawings, foundation drawings, and plant layout. Clients are welcome to visit our factory, also our equipment working site from former clients.

Sale services:
Our experienced technicians are available on the phone also the Internet, clients can get instance guidance by telephone, email, online service anytime and anywhere.

After-sale services:
Normally, the equipment warranty is 12 months since installation. To establish long term cooperation, we will regularly call and email our clients to check the equipment working condition and offer suggestions for maintenance.
Company Introduction
BOGDA Machinery Group is located in Europe and America (Hai'an) Industrial Park and Shanghai Fengxian (Hai'an) Industrial Park. It is a high-tech and innovative company dedicated to the research and development and manufacturing of plastic extrusion molding equipment. The company is people-oriented and innovative Development, with its unique corporate culture that has been brewing for many years, and the company’s eager attention to global economic development, it has continued to grow with its majestic momentum and quick response, making itself a large-scale and highly anticipated industry in this industry.

Leading technology and excellent quality have been highly recognized by authoritative departments and markets. Products are exported to more than 110 countries and regions such as Europe, America, the Middle East, Southeast Asia, South America, Russia, Turkey, Italy, Poland, Brazil, Romania, etc. Deeply trusted and praised by customers, the company has many subsidiaries such as pipeline equipment, sheet film intelligent equipment, intelligent automation, and granulation equipment. The company has a high-quality talent R&D team and more than 20 years of experience in the industry. A team of mechanical and electrical commissioning engineers, as well as an advanced machining base and a standardized assembly workshop. More than 600 sets of high-end plastic extrusion lines are produced every year.

The main products of the company are:
1. PVC/PP/PE wood plastic production lines
2. PVC/PP/ wide sheet production lines
3. PVC/UPVC door and window profiles, ceiling panels, wall panels, window sill panels, wall hanging panels and other profiles extrusion production lines
4. PC/PA/ABS and other profiles production lines
5. PVC pipe production lines
6. HDPE/PE/PVC/PPR/PERT solid wall pipe production lines, as well as HDPE/PE gas pipe production lines
7. Vertical and horizontal HDPE/PP/PVC corrugated pipe production lines & reinforced winding pipe production lines
8. Multi-layer and single-layer PE/PP/PS/HIPS/GPPS/PC/ABS/PLA/PET/PMMA/GPPS/APET/PETG sheet production line
9. EVA/POE/PVB/SGP film production line; TPU/TVB film and lithium battery separator production line
10. All kinds of PE/PP/PLA/PET pelletizing units
11. PVC/PE/PP automated centralized feeding system
12. PP meltblown fabric and various spunbond non-woven fabric production lines
13. SPC LVT PVC Floor Production Line
14. PVC foamed board extrusion production lines
15. Recycling auxiliary equipment related to extrusion line, such as extrusion mold, plastic shredder, plastic crusher, plastic pulverizer, cooling tower, automatic screw loader, hopper dryer, plastic mixer and etc.

BOGDA has advanced design concepts in the extrusion field, strives for perfection in product quality, and continues to improve in technology. It can provide customized solutions for each customer to meet the different needs of customers. Project planning, product positioning, plant planning, equipment installation and commissioning, customer staff training, equipment after-sales maintenance and other all-round services. Our advantage is to provide customers with desired, satisfactory, and high-quality products to help customers create the greatest Profits and business opportunities, customer success is our ultimate goal.
FAQ
1. How many electric, water, air need for the machines?
BOGDA: technical department supply the whole layout for workshop details.

2. Can I operate machine if don’t have experienced engineers?
BOGDA: (1) short-time engineers to customer company (5-15days)
(2) Year-time working as requirements

3. Any quality checking before shipment?
BOGDA: 100% confirm, run and test machines before shipment with quality certificate.

4. How long is the guarantee?
BOGDA: 12 months since the first day customer operates (except wear parts)

5. How can u help us when face some technical problem?
BOGDA: 24 hours by e-mail, message, calling. If problems happens need engineer we will arrange the closest or agent in local country, or send Chinese Engineers to solve in 2 weeks.

6. Where can we get spare part?
BOGDA: we choose International Brand that customer can find it in everywhere, such as Siemens, Schneider, Omron, Delixi etc, or send parts by DHL, Fedex, TNT and other express.
